MBY Industrial helical ball mill gearbox fair price
for building materials coal and mines
MODEL: MBY400,MBY450,MBY500,MBY560,MBY630,MBY710,MBY800,MBY900,MBY1000,MBY1100
RATIO: 1:4 1:4.5 1:5 1:5.6 1:6.3 1:7.1
Description:
For side drive device of tube mill, we specially configures high-performing MBY (MBYX) gearboxes as the primary gearbox.
The primary motor is connected to one side of the input shaft of the gearbox, and the auxiliary drive device is connected
to the other side. The small gear on the girth gear of the tube mill is connected through a dual connection coupler to
adjust the small gear. The small single gear drive device can be fixed designed either or automatically.
Technical Data:
Specification: 11
Stage: 1, gear pair with parallel axes
Driving speed ratio: maximum i=7.1
Rated power: P=200 kW ~5,000 kW
Advantages:
Optimized meshing accuracy of gears, lower noise, and high efficiency;
The housing is analyzed and optimized by FEM, with less deformation during operation process, and more stable operation;
Secured manufacturing quality and higher reliability;
Secured manufacturing quality and higher reliability;
Short lead time, and excellent cost performance ratio.
Applicable Fields:
Applied to crushing ore, coal sheets or cement clinker in industries of building materials, coal, and mines.
Application examples:
MBY710 used for cement production line with 5,000 T/d acetylene sludge for Shanxi Ruiheng Chemical Co., Ltd. and main driving of coal mill.
MBY900 used for 5,000 T/d cement clinker production line of Pu'er Kungang and main driving of coal mill.
MBY1000 used for 2,500 T/d cement grinding station of Anhui Dajiangye Group and main driving of cement mill.
Specifications:
Gear box type NO. |
Input Shaft |
Output Shaft |
i=4 |
i=4.5-5 |
i=5.6-6.3 |
i=7.1 |
g |
d |
l |
g |
d |
l |
g |
d |
l |
g |
d |
l |
Q |
D |
L |
MYB400 |
270 |
120 |
200 |
270 |
100 |
200 |
270 |
90 |
180 |
270 |
80 |
140 |
270 |
160 |
200 |
MBY450 |
300 |
120 |
220 |
300 |
120 |
200 |
300 |
100 |
180 |
300 |
90 |
160 |
300 |
180 |
220 |
MBY500 |
320 |
140 |
240 |
320 |
140 |
200 |
320 |
110 |
180 |
320 |
100 |
160 |
320 |
180 |
240 |
MBY560 |
340 |
160 |
250 |
340 |
160 |
200 |
340 |
120 |
200 |
340 |
110 |
180 |
340 |
200 |
260 |
MBY630 |
370 |
180 |
250 |
370 |
160 |
230 |
370 |
130 |
200 |
370 |
120 |
180 |
370 |
220 |
300 |
MBY710 |
390 |
200 |
280 |
390 |
160 |
250 |
390 |
150 |
220 |
390 |
140 |
200 |
390 |
260 |
340 |
MBY800 |
425 |
220 |
300 |
425 |
180 |
260 |
425 |
180 |
240 |
425 |
160 |
200 |
425 |
300 |
380 |
MBY900 |
455 |
240 |
340 |
455 |
200 |
260 |
455 |
180 |
260 |
455 |
180 |
220 |
455 |
300 |
400 |
MBY1000 |
485 |
260 |
380 |
485 |
240 |
280 |
485 |
200 |
280 |
485 |
200 |
250 |
485 |
320 |
420 |
MBY1100 |
520 |
280 |
400 |
520 |
260 |
300 |
520 |
220 |
300 |
520 |
220 |
280 |
520 |
360 |
440 |
Sampling detection by Jiangsu reducer Product Quality Supervision and Inspection Center(Authority Testing),ensure the quality before export:
Our company and workshop:
Tailong Group,located in Taixing city along riverside of the Yangzi River,is a national giant enterprise which Taixing People are proud of.It has developed in one of top 500 machinery industrial enterprises in China,playing a leading role in domestic reducer/transmission indutry.
The dominant product,the reducer is available in decades of series and several hundred thousand specifications.Equipped with advanced modular and dot line engagement technology,we have additionally developed series of high tech products such as TL modular gear retarded machine,TXP modular planet reducer,heavy load modular gear retarded machine,dot line engaged reducer,vertical grinder and edge drive grinder gearbox,joint,open-book,take-up gearbox used for aluminum metallurgy industry,three ring gear reducer,planetary wheel speed reducer,wind driven gearbox,transmission for hydro-power generation,nuclear circling pump driven gearbox,and various special non-standard gearboxes.Tailong Industrial Park has become the largest steel cord production base of national wide.Our wto-vane an threevane Roots blowers and high temperature blower are exported to South East Asia,Europe and America in batches.
Our products are certified with safety marks for mining products and recognized pass lifting industry type test.Tailong brand is recognized as the Chinese famous brand by national industrial and commercial bureau and Tailong reducer is awarded as the Chinese famous brand product.
The use range of some real images in boiler fields:
Some well-known partner of our customers:
FAQ:
Q1:What kinds of gearbox can you produce for us?
A1:Main products of our company:
1. Boiler grate speed reducer
2. Helical Gear Box
3. Gear Box
4. Crane Reducer
5. Planetary Gear Box
6. cycloidal pin gear speed reducer
7. Extruder Machine Reducer
8. Three Ring Gear Reducer
9. Sugar Cane Machine Reducer
10. Mixing Mill Gear Box
11. Mill Gear Box
12. Cooling Tower Reducer
13. Gear motor
14. Direct-connected gear reducer
15. Worm Gear Reducer
16. Cylinder Gear Reducer
17. Motorized pulleys
18. Star-wheel speed reducer
19. Brick machine speed reducer
20. Grain and oil machinery speed reducer
21. Backstop for gearbox
22. Soft teeth of gear
23. Moderate-hard teeth of gear
24. Hard teeth of gear, more than one hundred models and thousands of specifications.
Q2: What are the application of the gearbox reducer use?
A2:Products are widely used in ceramic, glass, food, metallurgy, beer & drink, printing and dyeing, textile, petrochemical engineering, warehouse logistics, wood-working machine, environmental protection equipment, printing and packaging, pharmacy, and leather. Products are sold in some countries and regions, such as Europe, America, and Southeast Asia, and it possesses dozens of distributors and after-sale service agents.
Q3: What about the quality control?
A3: We have a perfect QC system for the perfect products. A team who will detect the product quality and specification piece carefully, monitoring every production process until packing is complete, to ensure product safety into container.
Q4: How about the payment way?
A4: 30% payment in advanc, 70% payment before loading.
Other questions,welcome to write a inquiry and have a visit on our factory discuss the detailed business processes by mutual benefit between both of us!
