Hot-rolled Steel Ball Milling Production Line for Diameter 20mm Steel Ball

  • Hot-rolled Steel Ball Milling Production Line for Diameter 20mm Steel Ball
  • Hot-rolled Steel Ball Milling Production Line for Diameter 20mm Steel Ball
  • Hot-rolled Steel Ball Milling Production Line for Diameter 20mm Steel Ball
  • Hot-rolled Steel Ball Milling Production Line for Diameter 20mm Steel Ball
  • Hot-rolled Steel Ball Milling Production Line for Diameter 20mm Steel Ball
  • Hot-rolled Steel Ball Milling Production Line for Diameter 20mm Steel Ball
  • Hot-rolled Steel Ball Milling Production Line for Diameter 20mm Steel Ball
Model No.︰D20 Steel Ball
Brand Name︰Hot-rolled Steel Ball Milling Production Line
Country of Origin︰China
Unit Price︰US $ 489612.5 / unit
Minimum Order︰1 unit
Share on:

 Total 3 Related Items
Prev123

Product Description

Hot-rolled Steel Ball Milling Production Line


Description
Hot-rolled steel ball rolling is a new technology, is a breakthrough technology in manufacturing ball milling, being gradually replaced cast steel balls.
Our plant after engineering and technical personnel to fully study the ball rolling production line transformation, development and manufacturing of a new generation of ball rolling production line, and a complete set of automatic hot-rolled steel ball production line processes. Ball mill through many innovative design has the following characteristics :1, roller box overall design, good rigidity; 2, easy to adjust, easy to operate ; 3, lock solid, high stability; 4, guide plate replacement is simple, quick and efficient. Ball rolling production line for stable, efficient, high-equality operation to provide assurance. Furnace (usually natural gas) two kinds of patterns, induction furnace can provide users by induction heating and gas heating efficiency, low consumption of preparation programs; gas furnace with automatic step-structure, low air consumption, commonly used in large size of the hoe-rolled steel ball production line. Heat treatment (quenching) line for hot-rolled steel ball milling production line dedicated, continuous on-line, ball strong quenching, quenching process parameters stable. Continuous type furnace online and offline type two forms, there is a continuous line type exhaust preheat furnace insulation type and electric heating preheat insulation type, automatic control; offline trolley type furnace uses electric heating insulation, simple process easy to operate.

Technical Data
Ball milling production line also has the following features: 1, heat treatment into the quenching, after quenching (water) temperature is automatically controlled to ensure quenching quality; 2, roll with automatic rewind function, rolling card guarantee the roll from damage; 3, fixed feeding function, improve the finished product rate. The company developed the design and manufacture of hot rolled steel ball milling production line is fully automated production lines, up to the latest level of hot-rolled steel ball production.
Model
According to the specifications of the rolling ball milling varieties, our company development, design, manufacture series of hot-rolled steel ball milling production lines, including D20, D30, D40, D50, D60, D70, D80, D100, D120, D130, D150 hot-rolled ball milling complete production line, capable of producing Ø15~150 ball milling the specifications and a variety of steel sections, to meet different user requirements.
D20~D50 Ball Rolling Line Performance Indicators

No.
Type
Product Specifications(mm)
Capacity(tablets/min)

1
D20
Ø15, Ø20
120~140 pcs

2
D30
Ø20, Ø25, Ø30
100~140 pcs

3
D40
Ø20, Ø25, Ø30, Ø40
80~130 pcs

4
D50
Ø20, Ø25, Ø30, Ø40, Ø50
70~130 pcs

D20~D50 Main Function
1.Main motor frequency control, in order to achieve the needs of different specifications of different capacity;
2.Conveyor drive frequency control, adjustable ball into the quenching temperature;
3.Spiral quenching tank transmission frequency control, adjustable ball after quenching (water) temperature;
4.Cylinder sweltering heat tempered for tempering;
5.Rolls and guides to adjust the “manual type” and “electric-type” two ,to choose from;
6.Rolls automatic rewind function, user selectable .

Advantages
1.after the round bar on examination, by length ball cut into blanks
2.the blank prior to the rolling ball in a continuous furnace is heated to a suitable temperature.
3.After the red hot billet is fed into the ball mill, in two with a special spiral pass Between the rotating rolls forward, and is continuously rolled into balls. Each ball mill per minutes can be rolled into a 60 to 120 balls.
4.Red Hot rolled into balls immediately after entering the online heat hot standby quenching-back Heat treatment, high and steel balls to obtain uniform hardness.

Applicable Fields
1.after the round bar on examination, by length ball cut into blanks
2.the blank prior to the rolling ball in a continuous furnace is heated to a suitable temperature.

Price Terms︰FOB Shanghai
Payment Terms︰TT / LC
Packing︰fumigation wooden case
Lead Time︰60 days after the deposit
SKU︰2
Standards Certificate︰ISO9001:2008, ISO14001:2004
